Mondraker Chrono 2025 Bike

More Information
Brand	Mondraker
Suitable for	Everyone
Wheel Size	29-inch

Mondraker was founded in 2001 and is a brand dedicated to the design and production of high-performance mountain bikes, offering pioneering developments and advanced technologies in all categories.

Skip to the beginning of the images gallery

Details

Dirt, rocks, roots, mud, dust, water. Interconnected elements. Elements that convey emotions that reach you raw and unfiltered. Rediscover your love and passion for mountain biking with our hardtail.

Specifications

Frame and Forks

Frame: Chrono 29 Stealth Alloy, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable Routing, Boost 12 x 148mm rear axle
Forks: RockShox Judy Silver TK 29, 100mm, TurnKey, Solo Air, tapered steerer tube, 9 x 100mm axle, 30mm steel stanchions, 46mm offset. Settings: Poplock 2 pos remote compression (open / lock), rebound, air preload
Headset: ONOFF Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41 x 30.2 x 7 x 45º x 45º, bottom 51.9 x 40 x 8 x 45º x 45º

Drivetrain

Crankset: SRAM SX Eagle, Boost, DUB axle, Direct Mount chain ring, Small size: 170mm, Medium / Large / X-Large size: 175mm
Bottom Bracket: SRAM DUB BSA, sealed bearings, 73mm
Rear Derailleur: SRAM SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1 x 12, X-actuation 1:1
Cassette: SRAM PG-1210, 11-50 Tooth, 12 Speed
Chain: SRAM SX Eagle, 12 Speed, Powerlock

Braking/Shifting

Shifters: SRAM Trigger SX Eagle, 12 Speed, X-Actuation 1:1
Front Brake: SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear Brake: SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake Levers: SRAM Level, tooled reach adjust, lever pivot bushings

Wheels

Front Hub: Formula DC20LW, 9 x 100mm, cup & cone ball bearings, IS 6 bolts
Rear Hub: Formula MST148S-4SB, Boost 12 x 148mm, sealed bearings, IS 6 bolts, MS freehub
Rims: MDK-XP1 29 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes: CN round stainless steel
Front Tyre: Maxxis Ikon 29 x 2.20", 60TPI, wire bead
Rear Tyre: Maxxis Ikon 29 x 2.20", 60TPI, wire bead

Finishing Kit

Handlebars: ONOFF Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 740mm, 9º backsweep, 0º upsweep, 31.8mm barbore
Grips: ONOFF Twin, 1lock-on, 135mm
Stem: ONOFF Sulfur, 6061 T6 Alloy, 31.8mm barbore, rise: +/-7º, length: sizes Small / Medium: 60mm, size Large: 80mm, size X-Large: 90mm
Seatpost: ONOFF Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 27.2mm, length 400mm
Saddle: Mondraker XC Series, steel rail
