The most affordable model in the family, the base-spec Marin Nicasio is built around a smooth-riding and stylish Series 1 double-butted CrMo frame and fork and zippy 700C wheels, with room for up to 45mm tires. We’ve specced a 2 x 8-speed Shimano Claris drivetrain, wide WTB rubber, powerful Tektro mechanical discs and plenty of Marin components.
Technology
Beyond Road Geometry
Beyond Road Geometry offers a blend of endurance road handling with enhanced stability for off pavement use.
Steel Frame Construction
The Nicasio uses a Series 2 or Series 1 butted 4130 CrMo frame with disc brakes, full fender and rack mounts, and two to three bottle bosses.
Disc Brakes
Disc brakes provide smooth, controlled stopping in all conditions with minimal maintenance.
Tyre Clearance
The Nicasio frame and fork has clearance for up to 700C x 35mm or 650B x 47mm tires.
Specifications
Frame and Forks
- Frame: Steezy Double Butted CrMo Beyond Road, 700C Wheels, Beyond Road Geometry, Fender and Rack Mounts, Disc Mount
- Forks: CrMo, Fender and Rack Eyelets, IS Disc Mount
Drivetrain
- Crankset: FSA Tempo Compact, 50 / 34 Tooth
- Front Derailleur: Shimano Claris
- Rear Derailleur: Shimano Claris 8-Speed
- Cassette: SunRace 8-Speed, 11-32 Tooth
- Chain: KMC Z8
Braking/Shifting
- Front Brake: Tektro MDC400, Road Mechanical, 160mm Rotor
- Rear Brake: Tektro MDC400, Road Mechanical, 160mm Rotor
- Brake Levers: Shimano with Integrated Shifters
Wheels
- Front Hub: Forged Aluminum Alloy, Disc, 32 Hole
- Rear Hub: Forged Aluminum Alloy, Disc, 32 Hole
- Rims: Marin Aluminum Double Wall, 19mm Inner, Disc Specific
- Tyres: WTB Exposure, 700 x 36c, Wire Bead
Finishing Kit
- Handlebars: Marin Butted Alloy, Compact 16º Flared Drop
- Grips: Marin Comfort Tape
- Stem: Marin 3D Forged Alloy
- Seatpost: Marin Alloy, 27.2mm
- Saddle: Marin Beyond Road Concept
