SP SV-8 Rim Brake Dynamo Front Hub

This QR type hub is ideally suited to 20-inch wheels at 6V3W output or 26-inch/700C wheel at 6V2.4W output. It is perfect for rim brakes.The model is designed for 20-inch wheel at a 6V3W rating. It is also ready for use with 26-inch / 700c wheels at 6V2.4W outputs. After the speed reaches 15 km/h, SV-8 (For 26-inch/700C) output is almost the same as the 6V3W hub. Therefore, SV-8 offers sufficient power for racers during the races.

Technology

SV-8 Dynamo Hub 6V3W for 400~536mm

SV-8 Series dynamo hubs are not only the smallest in its appearance, but also are the lightest at the market. This model is designed for wheel size from 400 to 536mm at a 6V3W rating. It is also ready for use with 700c wheels at 6V2.4W output.

SP respects the 6V3W German standard. All SP dynamo hubs are compatible with standard hub dynamo products including dynamo lamps and converters for USB powered devices. Enjoy small and light.

Specification

• Axle Type: QR
• Brake Type: Rim Brake
• Spoke PCD: 52mm
• Flange Diameter: 66mm
• O.L.D Axle Size: 100mm
• Max Hub Diameter: 58mm
• Spoke Holes: 32H
• Weight: 357g
