Enduro ABEC 3 607 LLB Bearings

607 LLB - ABEC-3 radial Bearing (C3 clearance) - 7mm x 19mm x 6mm

Not a particularly popular bearing, this radial bearing has been used primarily as a pedal bearing. This ABEC-3 radial bearing features 52100 High-Carbon Chromium alloy races paired with Grade 10 balls and full-contact, dual-lip labyrinth (LLB) seals to withstand the outside elements, and to contain the 90% fill Mobil XHP 222 high pressure water proof synthetic grease.

The Enduro line of bearings are available in high-carbon chromium steel, 440C stainless steel, ceramic-hybrid and XD-15 with ceramic or stainless balls. Our bearings are always engineered with deepest groove races possible to accommodate the largest balls possible and feature dual-lip seals that ride in a micro-groove creating a full labyrinth to provide superior protection against the elements.

Bearings Seals

LLB Seals

Enduro's most popular light contact seal. LLB seals are comprised of Nitrile material rubber with a steel insert and ideally suited for constantly spinning bottom bracket and hub bearings. Rather than one thick 2RS seal lip rubbing on a blunt surface, LLB type utilizes two razor thin sealing lips riding in the bearing race groove. The outer lip keeps the water and contaminants out, while the inner lip retains grease for smooth function and longer intervals between servicing.

Features

• Static Load: 286lbf / 1.27kN
• Weight: 7.4g
