Kona Sutra LTD 2025 Bike
| Brand | Kona |
|---|---|
| Colour | Gloss Bone |
| Suitable for | Everyone |
| Wheel Size | 29-inch |
The Sutra LTD is one of those bikes that just changes everything. You thought you were a mountain biker, but you find yourself sneaking off on adventures and enjoying the drop bars on the LTD. You thought you were a roadie but find yourself absolutely destroying singletrack when no one else is looking and suddenly getting rad is all you wanna do! That's the best part about the Sutra LTD-it broke the mould of what a bike has to be. It's got bigger tires, burlier construction, and enough mounts to hold a horse. But who needs a horse when this is your horse?
The long-regarded Sutra LTD has steadily evolved into a progressive drop bar off-road rider’s dream: true mountain bike tires, a real dropper post, modern yet sensible and capable geometry, and ample frame storage capability while still boasting a fun-sized sloping top tube with cornering-worthy standover clearance. All while touting the supple steel ride quality that made it that instantaneous cult classic. Plus year-on-year-on-year durability. Is it perfect? If it’s not, then this is as close as perfection gets.
Features
- The Sutra LTD has a longer reach, wider bar, and slacker headtube than the Sutra and previous-generation Sutra LTD, creating a more stable feel when descending on technical terrain
- A short seat tube provides the perfect home for 100mm dropper posts. Time to get sendy!
- Two sets of water bottle bosses under the top tube are perfect for mounting custom frame bags
- Fork mounts and bento box mounts offer more gear-hauling options
- Massive tyre clearance means you can run up to a 29x2.25" tyre. The Sutra LTD comes with 2.25" Maxxis Rekon Race tires
- Dropouts allow 160/180mm rotors for increased braking performance carrying heavier loads on steeper and more demanding terrain
- Compared to the original Sutra LTD, the geometry is more aggressive for more dynamic riding. The headtube angle is 69.5°, the fork offset is 55mm, and the seat tube angle has increased .5°
Specification
Frame and Forks
- Frame: Kona Cromoly Butted
- Forks: Kona Project Two Cromoly Disc Touring Fork
- Headset: FSA No.1/No.10
Drivetrain
- Crankset: Shimano Deore
- Chainrings: 34T Deore
- Bottom Bracket: Shimano Deore 73mm
- Rear Derailleur: Shimano GRX 12-Speed
- Cassette: Shimano Deore 10-51T 12-Speed
- Chain: Shimano Deore
Braking / Shifting
- Shifters: Shimano GRX with dropper lever
- Brakes: Shimano GRX
- Front Rotor: Shimano 180mm
- Rear Rotor: Shimano 180mm
- Brake Levers: Shimano
Wheels
- Rims: WTB KOM Team i27 TCS 2.0
- Front Hub: Formula 100 x 12mm
- Rear Hub: Formula 142 x 12mm
- Spokes: Stainless Black 14g
- Front Tyre: Maxxis Rekon Race EXO TR 29 x 2.25"
- Rear Tyre: Maxxis Rekon Race EXO TR 29 x 2.25"
Finishing Kit
- Handlebars: Kona Road
- Grips: Kona Cork Tape
- Stem: Kona Road Deluxe
- Seatpost: TranzX Dropper +RAD Internal 31.6mm
- Seat Clamp: Kona Clamp
- Saddle: WTB Volt
- Pedals: Not Included
More Info
- Colour: Gloss Bone with Charcoal Decals
